215
APPENDIX
B-8 FBM Functionality Test Procedure:
1. Writing amount of data into controller volume, about 5GB or
bigger.
2. Waiting for few seconds, power failed system by remove the
power cable.
3. Power on system, and press Tab/F6 to login controller.
4. Check the controller event log, make sure the event shows
“Power On With Battery Backup”.
B-9 FBM Specifications
Mechanical
• Module Dimension (W x H x D):
- with battery: 64.4 x 16.97 x 127 mm
- with supercap: 64.4 x 18.72 x 127 mm
• FBM Connector: (1*14) box header
Environmental
• Operating Temperature: 0°C to +50°C
• Cache Memory Size Supported: up to 2GB (super capacitor/bat-
tery) or 8GB (battery)
