149
WEB BROWSER-BASED CONFIGURATION
Note:
In “Quick Create”, your volume set is automatically configured
based on the number of disks in your system. Use the “Raid
Set Functions” and “Volume Set Functions” if you prefer to
customize your volume set, or RAID 30/50/60 volume set.
6.5 Raid Set Functions
Use the “Raid Set Function” and “Volume Set Function” if you pre-
fer to customize your volume set. Manual configuration can provide
full control of the RAID set settings, but it will take longer to com-
plete than the “Quick Volume/Raid Setup” configuration. Select the
“Raid Set Function” to manually configure the RAID set for the first
time or delete and reconfigure existing RAID sets. (A RAID set is a
group of disks containing one or more volume sets.)
6.5.1 Create Raid Set
To create a RAID set, click on the “Create Raid Set” link. A “Select
The Drive For RAID Set” screen is displayed showing the drive(s)
connected to the current controller and enclosures. Click on the
selected physical drives within the current RAID set. Enter 1 to 15
alphanumeric characters to define a unique identifier for a RAID
set. The default RAID set name will always appear as “Raid Set
#”. Tick on the “Confirm The Operation” check box and click on
the “Submit” button on the screen; the RAID set will start to ini -
tialize. If you have available disk member, you can repeat above
procedures to define another RAID sets.
