BIOS CONFIGURATION
99
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Hdd Power Management
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Hdd Power Management
Stagger Power On
Time To Low Power Idle
Time To Low RPM Mode
Time To Spin Down Hdd
Time To Spin Down Hdd
Spin Down Hdd
Disabled
1
3
5
10
15
20
30
40
60
Disabled
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Hdd Power Management
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Hdd Power Management
Stagger Power On
Time To Low Power Idle
Time To Low RPM Mode
Time To Spin Down Hdd
Time To Low RPM Mode
Low RPM Mode
Disabled
10
20
30
40
50
60
Disabled
3.7.7.3 Time To Low RPM Mode
This function can automatically spin disks at lower RPM if there
have not been used during the setting idle time. The values can
be selected “Disabled” or within the range 10 to 60 minutes.
3.7.7.4 Time To Spin Down Idle Hdd
This function can automatically spin down the drive if it hasn’t
been accessed for a certain amount of time. This value is used
by the drive to determine how long to wait (with no disk activity,
before turning off the spindle motor to save power). The values
can be selected “Disabled” or within the range 1 to 60 minutes.
