6 activate failed disk, 7 identify selected drive, Bios configuration – Areca 24/4 Internal/External Port Pcie 3.0 12 Gb/s SAS/SATA Raid Controller 2Gb Cache User Manual
Page 82
BIOS CONFIGURATION
82
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Physical Drives
Physical Drive Function
View Drive Information
Create Pass-Through Disk
Modify Pass-Through Disk
Delete Pass-Through Disk
Set Disk To Be Failed
Activate Failed Disk
Identify Selected Drive
Identify Enclosure
Set Disk To Be Failed
Select The Drive
E#1Slot#2 : 500.1GB Pass Through HDS725050KL360
Delete Pass-Through
No
Yes
Are you Sure?
No
Yes
3.7.4.6 Activate Failed Disk
It forces the current “failed” disk in the system to be back on-
line. “Activate Failed Disk” function has no effect on the removed
disks, because a “removed” disk does not give the controller a
chance to mark it as “failure”.
3.7.4.7 Identify Selected Drive
To prevent removing the wrong drive, the selected disk fault LED
indicator will light for physically locating the selected disk when
the “Identify Selected Device” is selected.
