BIOS CONFIGURATION
84
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Raid System Function
3.7.5.1 Mute The Alert Beeper
The “Mute The Alert Beeper” function item is used to control the
SAS RAID controller beeper. Select
Yes
and press the
Enter
key
in the dialog box to turn the beeper off temporarily. The beeper
will still activate on the next event.
3.7.5.2 Alert Beeper Setting
The “Alert Beeper Setting” function item is used to “Disabled” or
“Enabled” the SAS RAID controller alarm tone generator. Select
“Disabled” and press the
Enter key in the dialog box to turn the
beeper off.
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Raid System Function
Raid System Function
Mute The Alert Beeper
Alert Beeper Setting
Change Password
JBOD/RAID Function
Background Task Priority
SATA NCQ Support
HDD Read Ahead Cache
Volume Data Read Ahead
Hdd Queue Depth Setting
Empty HDD Slot LED
Controller Fan Detection
Auto Activate Raid Set
Disk Write Cache Mode
Write Same Support
Capacity Truncation
Mute The Alert Beeper
Mute Alert Beeper
No
Yes
