WEB BROWSER-BASED CONFIGURATION
Note:
If you configure the HTTP Port Number to 0, the HTTP
console
will be closed.
6.9.5 Alert By Mail Configuration
To configure the SAS RAID controller e-mail function, move the
cursor bar to the main menu and click on the “System Controls”
link. The “System Controls” menu will show all items. Move the
cursor bar to the “Alert By Mail Configuration” item, then select
the desired function. This function can only be set via web-based
configuration.
The firmware contains a SMTP manager monitoring all system
events. Single or multiple user notifications can be sent via “Plain
English” e-mails with no software required. (Please refer to sec-
tion 5.6 ArcHTTP Configuration of SMTP Server Configuration, Mail
Address Configuration and Event Notification Configuration.
)
