Page 83: Bios configuration
BIOS CONFIGURATION
83
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
Hdd Power Management
Ethernet Configuration
View System Events
Clear Event Buffer
Hardware Monitor
System information
Physical Drive Information
Physical Drive function
View Drive Information
Create Pass-Through Disk
Modify Pass-Through Disk
Delete Pass-Through Disk
Identify Selected Drive
Identify Enclosure
Identify Selected Drive
Select The Drive
E#1Solt#2 : 500.1GB : HDS725050KLA360
E#1Solt#03 : 500.1GB :
RaidSet Member:
ST3500630NS
E#1Solt#04 : 400.1GB :
RaidSet Member:
Hitachi HDT725040VLA360
E#1Solt#05 : 400.1GB :
RaidSet Member:
Hitachi HDT725040VLA360
E#1Solt#06 : 400.1GB :
RaidSet Member:
Hitachi HDT725040VLA360
E#1Solt#07 : 500.1GB :
RaidSet Member:
HDS725050KL360
E#1Solt#08 : 500.1GB :
RaidSet Member:
ST3500630NS
E#1Solt#02 : 500.1GB : RaidSet Member: HDS725050KLA360
Please Check The Device’s LED
3.7.4.8
Identify Enclosure
To prevent removing the wrong enclosure, the selected Areca
expander enclosure all disks fault LED indicator will light for
physically locating the selected enclosure when the “Identify
Enclosure” is selected. This function will also light the enclosure
LED indicator, if it is existed.
3.7.5 Raid System Function
To set the “Raid System Function”, move the cursor bar to the
main menu and select the “Raid System Function” item and then
press
Enter
key. The “Raid System Function” menu will show
multiple items. Move the cursor bar to an item, and then press
Enter
key to select the desired function.
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Physical Drive Information
Physical Drive Function
View Drive Information
Create Pass-Through Disk
Modify Pass-Through Disk
Delete Pass-Through Disk
Set Disk To Be Failed
Activate Failed Disk
Identify Selected Drive
Identify Enclosure
Identify Enclosure
Select The Enclosure
Enclosure#2 : Areca x28-05.75.1.37 000
Enclosure#3 : Areca x28-05.75.1.37 000
Enclosure#4 : Areca x28-05.75.1.37 000
Enclosure#5 : Areca x28-05.75.1.37 000
Enclosure#1 : ARECA SAS RAID Adapter V1.0
