BIOS CONFIGURATION
61
Note:
2. If a disk drive fails during RAID set expansion and a hot
spare is available, an auto rebuild operation will occur
after the RAID set expansion completes.
3. RAID 30/50/60 doesn't support the "Expand Raid Set".
4.
RAID set expansion is a quite critical process, we
strongly recommend customer backup data before ex
pand. Unexpected accident may cause serious data cor-
ruption.
• Migrating
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Raid Set Function
Raid Set Function
Create Raid Set
Delete Raid Set
Expand Raid Set
Offline Raid Set
Activate Raid Set
Create Hot Spare
Delete Hot Spare
Rescue Raid Set
Raid Set Information
Raid Set information
The Raid Set Information
Raid Set Name : Raid Set # 00
Member Disks : 2
Raid State : Migrating
Total Capacity : 800.0GB
Free Capacity : 800.0GB
Min Member Disk Size : 400.0GB
Member Disk Channels : .E1S1.E1S2.
Migration occurs when a disk is added to a RAID set. Migrating
state is displayed in the RAID state area of “The Raid Set
Information” screen when a disk is being added to a RAID set.
Migrating state is also displayed in the associated volume state
area of the “Volume Set Information” which belongs this RAID
set.
3.7.2.4 Offline Raid Set
This function is for customer being able to unmount and re-
mount a multi-disk volume. All Hdds of the selected RAID set
will be put into offline state and spun down and fault LED will be
in fast blinking mode. User can remove those Hdds and insert
those Hdds on the others controller empty slots without needing
power down the controller to perform the online array roaming.
