3 change password, Bios configuration – Areca 24/4 Internal/External Port Pcie 3.0 12 Gb/s SAS/SATA Raid Controller 2Gb Cache User Manual
Page 85
BIOS CONFIGURATION
85
3.7.5.3 Change Password
The manufacture default password is set to 0000.
The
password option allows user to set or clear the password pro-
tection feature. Once the password has been set, the user can
monitor and configure the controller only by providing the cor
-
rect password. This feature is used to protect the internal RAID
system from unauthorized access. The controller will check the
password only when entering the main menu from the initial
screen. The system will automatically go back to the initial
screen if it does not receive any command in 5 minutes. To set
or change the password, move the cursor to “Raid System Func-
tion” screen, press the “Change Password” item. The “Enter New
Password” screen will appear. Do not use spaces when you enter
the password, If spaces are used, it will lock out the user. To dis-
able the password, only press
Enter
key in both the “Enter New
Password” and “Re-Enter New Password” column. The existing
password will be cleared. No password checking will occur when
entering the main menu.
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Raid System Function
Raid System Function
Mute The Alert Beeper
Alert Beeper Setting
Change Password
JBOD/RAID Function
Background Task Priority
SATA NCQ Support
HDD Read Ahead Cache
Volume Data Read Ahead
Hdd Queue Depth Setting
Empty HDD Slot LED
Controller Fan Detection
Auto Activate Raid Set
Disk Write Cache Mode
Write Same Support
Capacity Truncation
Alert Beeper Setting
Alert Beeper Setting
Enabled
Disabled
