Bios configuration – Areca 24/4 Internal/External Port Pcie 3.0 12 Gb/s SAS/SATA Raid Controller 2Gb Cache User Manual
Page 77
BIOS CONFIGURATION
77
Note:
Power failure may damage the migration data. Please
backup the RAID data before you start the migration func-
tion.
To expand an existing volume noticed:
•
Only the last volume can expand capacity.
•
When expand volume capacity, you can’t modify stripe size or
modify RAID revel simultaneously.
•
You can expand volume capacity, but can’t reduce volume
capacity size.
•
After volume expansion, the volume capacity can not be
decreased.
For greater 2TB expansion:
•
If your system installed in the volume, don't expand the
volume capacity greater 2TB, currently OS can’t support boot
up from a greater 2TB capacity device.
•
Expand over 2TB used 64bit LBA mode. Please make sure
your OS supports 64bit LBA before expand it.
3.7.3.4.2 Volume Set Migration
Migrating occurs when a volume set is migrating from one RAID
level to another, when a volume set strip size changes, or when
a disk is added to a RAID set. Migration state is displayed in the
volume state area of the “Volume Set Information” screen.
