BIOS CONFIGURATION
64
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Raid Set Function
Raid Set Function
Raid Set
Delete Raid Set
Expand Raid Set
Offline Raid Set
Activate Raid Set
Create Hot Spare
Delete Hot Spare
Rescue Raid Set
Raid Set Information
Delete Hot Spare
Select The HotSpare Device To Be Deleted
[ ]E#1Solt#3 : 500.1GB : ST3500630NS
[*]E#1Solt#3 : 500.1GB : ST3500630NS
Delete HotSpare?
No
Yes
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Raid Set Function
Raid Set Function
Raid Set
Delete Raid Set
Expand Raid Set
Offline Raid Set
Activate Raid Set
Create Hot Spare
Delete Hot Spare
Rescue Raid Set
Raid Set Information
Rescue Raid Set
Enter the Operation Key
3.7.2.8 Rescue Raid Set
When the system is powered off in the RAID set update/creation
period, it possibly could disappear due to this abnormal condi-
tion. The “RESCUE” function can recover the missing RAID set
information. The RAID controller uses the time as the RAID set
signature. The RAID set may have different time after the RAID
set is recovered. The “SIGANT” function can regenerate the sig-
nature for the RAID set.
Note:
Please contact us to make sure if you need to use rescue
function. Improperly usage may cause configuration
corruption.
