INTRODUCTION
14
ARC-1880/1882 series controller field-proven compatibility with
operating systems, motherboards, applications and device drivers.
Easy RAID Management
The controllers contain an embedded McBIOS RAID manager that
can access via hot key at M/B BIOS boot-up screen. This pre-boot
McBIOS RAID manager can use to simplify the setup and manage-
ment of RAID controller. The controller firmware also contains a
browser-based McRAID storage manager which can be accessed
through the Ethernet port or ArcHTTP proxy server in Windows,
Linux, FreeBSD and more environments. The McRAID storage
manager allows local and remote for all storage configuration and
management needs from standard web browser. The ArcSAP quick
manager can scan for multiple RAID units in the local and remote
systems and provide an effective mechanism to configure and
monitor your RAID units.
1.2 Features
Controller Architecture
• Dual core RAID-on-Chip (ROC) 1.2GHz processor
• PCIe 3.0 x8 lane host interface
• 2GB on-board DDR3-1866 SDRAM with ECC (ARC-1883i/LP/x)
• One 240-pin DIMM socket for 2GB(default) DDR3-1866, 1RX8,
ECC module (ARC-1883ix-12/16/24)
- up to 4GB or 8GB DDR3-1866, 1RX8, Unbuffered/Registered
ECC module or
- up to 4GB or 8GB DDR3-1600, 2RX8, Unbuffered/Registered
ECC module
• Write-through or write-back cache support
• Support up to 4/8/12/16/24 internal or 4/8 external 12Gb/s SAS
ports
• Multi-adapter support for large storage requirements
• BIOS boot array support for greater fault tolerance
• Supports up to 256 SATA or SAS devices using SAS expanders
• Boot support for the uEFI host BIOS
• DataBolt™ Bandwidth Optimizer for balance faster host and
slower SAS or SATA devices. (for ARC-1883ix)
• Redundant flash image for controller availability
