BIOS CONFIGURATION
52
Note:
The manufacture default password is set to
0000; this
password can be modified by selecting “Change Password”
in the “Raid System Function
”
section.
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
Hdd Power Management
Ethernet Configuration
View System Events
Clear Event Buffer
Hardware Monitor
System information
Quick Volume/Raid Setup
Verify Password
3.7 Main Menu
The main menu shows all functions that are available for executing
actions, which is accomplished by clicking on the appropriate link.
Option
Description
Quick Volume/Raid Setup
Create a default configuration based on the number
of physical disk installed
Raid Set Function
Create a customized RAID set
Volume Set Function
Create a customized volume set
Physical Drives
View individual disk information
Raid System Function
Setup the RAID system configuration
Hdd Power Management
Manage HDD power based on usage patterns
Ethernet Configuration
LAN port setting
View System Events
Record all system events in the buffer
Clear Event Buffer
Clear all information in the event buffer
Hardware Monitor
Show the hardware system environment status
System Information
View the controller system information
