BIOS CONFIGURATION
90
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Raid System Function
Raid System Function
Mute The Alert Beeper
Alert Beeper Setting
Change Password
JBOD/RAID Function
Background Task Priority
SATA NCQ Support
HDD Read Ahead Cache
Volume Data Read Ahead
Hdd Queue Depth Setting
Empty HDD Slot LED
Controller Fan Detection
Auto Activate Raid Set
Disk Write Cache Mode
Write Same Support
Capacity Truncation
Hdd Queue Depth Setting
HDD Queue Depth
1
2
4
8
16
32
16
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Raid System Function
Raid System Function
Mute The Alert Beeper
Alert Beeper Setting
Change Password
JBOD/RAID Function
Background Task Priority
SATA NCQ Support
HDD Read Ahead Cache
Volume Data Read Ahead
Hdd Queue Depth Setting
Empty HDD Slot LED
Controller Fan Detection
Auto Activate Raid Set
Disk Write Cache Mode
Write Same Support
Capacity Truncation
Empty HDD Slot LED
Empty Slot Led
ON
OFF
ON
3.7.5.10 Empty HDD Slot LED
The firmware has added the "Empty HDD Slot LED" option to
setup the fault LED light "ON "or "OFF" when there is no HDD
installed. When each slot has a power LED for the HDD installed
identify, user can set this option to "OFF ". Choose option "ON",
the SAS RAID controller will light the fault LED; if no HDD
installed.
