HARDWARE INSTALLATION
42
SNMP agent function and no additional agent software inquired
on your server system. If you need additional information about
installation and start-up this function, see the section 6.8.4
“
SNMP Configuration
” of the user manual.
• In-Band-Using PCIe Host Bus Interface
In-band interface refers to management of the SNMP data of
12Gb/s SAS controllers from a PCIe host bus. In-band interface
is simpler than out-of-band interface for it requires less hard-
ware in its configuration. Since the 12 Gb/s SAS RAID controller
is already installed in the host system, no extra connection is
necessary. Just load the necessary in-band
Areca SNMP extension
agent for the controllers. Before launching the SNMP agent in
the sever, you need first to enable the firmware-embedded SNMP
community configuration and install Areca SNMP extension agent
in your server system. If you need additional information about
installation and start-up the function, see the SNMP Operation &
Installation section in the Appendix D of the user manual.
Single Admin Portal (ArcSAP) Monitor
This utility can scan for multiple RAID units in the local and remote
systems and provide an effective mechanism to configure and
monitor your RAID units. For additional information, see the utility
manual (ArcSAP) in the packaged CD or download it from the web
site
http://www.areca.com.tw
.
