BIOS CONFIGURATION
103
3.7.8.5 SMTP Port Number
To manually configure the “SMTP Port Number” of the control
-
ler, move the cursor bar to the main menu “Ethernet Configu
-
ration” function item and then press
Enter
key. The “Ethernet
Configuration” menu appears on the screen. Move the cursor
bar to “SMTP Port Number” item, then press
Enter
key to show
the default address setting in the RAID controller. You can then
reassign the default “SMTP Port Number” of the controller.
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Ethernet Configuration
Ethernet Configuration
DHCP Function : Enable
Local IP Address : 192.168.001.100
HTTP Port Number : 80
Telnet Port Number : 23
SMTP Port Number : 25
EtherNet Address : 00.04.D9.7F.FF.FF
EtherNet Address : 00.04.D9.7F.FF.FF
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Ethernet Configuration
Ethernet Configuration
DHCP Function : Enable
Local IP Address : 192.168.001.100
HTTP Port Number : 80
Telnet Port Number : 23
SMTP Port Number : 25
EtherNet Address : 00. 04. D9.7F .FF. FF
SMTP Port Number : 25
Edit The SMTP Port Number
0025
0
3.7.8.6 Ethernet Address
Each Ethernet port has its unique Mac address, which is also
factory assigned. Usually, Ethernet address is used to uniquely
identify a port in the Ethernet network.
