BIOS CONFIGURATION
86
3.7.5.4 JBOD/RAID Function
JBOD is an acronym for “Just a Bunch Of Disk”. A group of hard
disks in a RAID box are not set up as any type of RAID configur-
ation. All drives are available to the operating system as an
individual disk. JBOD does not provide data redundancy. User
needs to delete the RAID set, when you want to change the
option from the RAID to the JBOD function.
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Raid System Function
Raid System Function
Mute The Alert Beeper
Alert Beeper Setting
Change Password
JBOD/RAID Function
Background Task Priority
SATA NCQ Support
HDD Read Ahead Cache
Volume Data Read Ahead
Hdd Queue Depth Setting
Empty HDD Slot LED
Controller Fan Detection
Auto Activate Raid Set
Disk Write Cache Mode
Write Same Support
Capacity Truncation
Change Password
Enter New Password
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Raid System Function
Raid System Function
Mute The Alert Beeper
Alert Beeper Setting
Change Password
JBOD/RAID Function
Background Task Priority
SATA NCQ Support
HDD Read Ahead Cache
Volume Data Read Ahead
Hdd Queue Depth Setting
Empty HDD Slot LED
Controller Fan Detection
Auto Activate Raid Set
Disk Write Cache Mode
Write Same Support
Capacity Truncation
JBOD/RAID Function
JBOD
RAID
JBOD/RAID Function
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
