BIOS CONFIGURATION
55
• Use 64bit
LBA
This option use 16 bytes CDB instead of 10 bytes. The maximum
volume capacity up to 512TB. For any hard disk drives working
in the 4K native mode in the Raid set, the volume set directly
sets and exposes 4KB sector size to the operating system. This
option works on different OS which supports 16 bytes CDB.
Such as:
Windows 2003 with SP1 or later
Linux kernel 2.6.x or later
• Use 4K Block
This option uses 16 bytes CDB and changes the sector size from
default 512 bytes to 4k bytes. Windows XP only supports maxi
-
mum volume capacity is up to 16TB.
A single volume set is created and consumes all or a portion of
the disk capacity available in this RAID set. Define the capacity of
volume set in the “Available Capacity” popup. The default value
for the volume set, which is 100% of the available capacity, is
displayed in the selected capacity. use the
UP
and
DOWN
arrow
key to set capacity of the volume set and press
Enter
key to ac-
cept this value. If the volume set uses only part of the RAID set
capacity, you can use the “Create Volume Set” option in the main
menu to define additional volume sets.
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Quick Volume/Raid Setup
Total 5 Drives
Raid 0
Raid 1 + 0
Raid 1 + 0 + Spare
Raid 3
Raid 5
Raid 3 + Spare
Raid 5 + Spare
Raid 6
Raid 6 +Spare
Raid 6
Available Capacity : 2400.0GB
Selected Capacity: 2400.0GB
