APPENDIX
D-3-1 Using ArcHTTP
The HTTP management software (ArcHTTP) runs as a service or
daemon, and have it automatically start the proxy for all con
-
trollers found. This way the controller can be managed remotely
without having to sign in the server. The HTTP management soft-
ware (ArcHTTP) also has integrated the ability of sending SNMP
trap. Please reference chapter 5. ArcHTTP Proxy Server Installa
-
tion section to install it. The ArcHTTP proxy server will automati
-
cally assign one additional port for setup its configuration. If you
want to change the “archttpsrv.conf” setting up of ArcHTTP proxy
server configuration, for example: General Configuration, Mail
Configuration, and SNMP Configuration, please start Web Browser
http:\\localhost: Cfg Assistant. Such as http:\\localhost: 81. The
port number for the first controller McRAID storage manager is
ArcHTTP proxy server configuration port number plus 1.
To enable the controller to send the SNMP traps to client SNMP
manager using the IP address assigned to the operating system,
such as Net-SNMP manager, you can simply use the SNMP
function on the ArcHTTP proxy server software. To enable the
RAID controller SNMP traps sending function, click on the “SNMP
Configuration” link. The ArcHTTP proxy only provide one direction
to send the trap to the SNMP manager without needing to install
the SNMP extension agent on the host. If SNMP manager requests
to query the SNMP information from RAID controller, please refer
the D-3-2 section. Using Onboard NIC and D-3-3 section. Using
in-band PCI + SNMP extension agent.
For detailed information on using ArcHTTP to send the SNMP
traps, please see SNMP Traps Configuration section on 5.6
ArcHTTP Configuration.
Note:
Event Notification Table refers to Appendix E.
After you confirm and submit configurations, you can use
"Generate Test Event" feature to make sure these settings
are correct.
