Page 104
BIOS CONFIGURATION
104
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Alert By Mail Config
Alert By Mail Config
SMTP Server IP Addr : 000.000.000.000
Mail Sender Name :
Mail Sender Address :
Mail Account :
Mail Account Passwd :
EventNotification1 : Enter
EventNotification2 : Enter
EventNotification3 : Enter
EventNotification4 : Enter
SMTP Server IP Addr : 000.000.000.000
3.7.9 Alert By Mail Config
To configure the 6Gb/s SAS RAID controller e-mail function, move
the cursor bar to the main menu and click on the “Alert By Mail
Config” link. The “Alert By Mail Config” menu will show all items.
Move the cursor bar to the “Alert By Mail Config” item, then select
the desired function.
3.7.10 View System Events
To view the SAS RAID controller’s system events information,
move the cursor bar to the main menu and select the “View Sys-
tem Events” link, then press the
Enter
key. The SAS RAID con-
troller’s events screen appear.
Choose this option to view the system events information: Timer,
Device, Event type, Elapsed Time, and Errors. The RAID controller
does not have a build-in real time clock. The time information is
the relative time from the SAS RAID controller powered on.
