BIOS CONFIGURATION
80
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Physical Drive Information
Select The Drive
E#1Solt#2 : 500.1GB : HDS725050KLA360
E#1Solt#03 : 500.1GB :
RaidSet Member:
ST3500630NS
E#1Solt#04 : 400.1GB :
RaidSet Member:
Hitachi HDT725040VLA360
E#1Solt#05 : 400.1GB :
RaidSet Member:
Hitachi HDT725040VLA360
E#1Solt#06 : 400.1GB :
RaidSet Member:
Hitachi HDT725040VLA360
E#1Solt#07 : 500.1GB :
RaidSet Member:
HDS725050KL360
E#1Solt#08 : 500.1GB :
RaidSet Member:
ST3500630NS
E#1Solt#02 : 500.1GB : RaidSet Member: HDS725050KLA360
E#2 Solt# - SAS
Model Name : ST380013AS
Serial Number : 5JV944ZF
Firmware Rev. : A600
Disk Capacity : 80.0 GB
Current SAS : 3G
Supported SAS : 3G
Device State : RaidSet Member
Timeout Count : 0
Media Errors : 0
Rotation Speed : 15015
SMART State : O.K.
3.7.4.1 View Drive Information
When you choose this option, the physical disks connected to
the SAS RAID controller are listed. Move the cursor to the
desired drive and press
Enter
key to view drive information.
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Physical Drive Information
Physical Drive Function
View Drive Information
Modify Pass-Through Disk
Delete Pass-Through Disk
Identify Selected Drive
Identify Enclosure
Create Pass-Through
Select The Drive
E#1Solt#2 : 500.1GB : Up..360
E#1Solt#8 : 500.1GB : Free
:
ST3500630NS
E#1Solt#9 : 400.1GB : Free
:
Hitachi HDT725040VLA360
E#1Solt#10 : 400.1GB : Free
:
Hitachi HDT725040VLA360
E#1Solt#11 : 400.1GB : Free
:
Hitachi HDT725040VLA360
E#1Solt#12 : 500.1GB : Free
:
HDS725050KL360
E#1Solt#7 : 500.1GB : Free : HDS725050KLA360
Create Pass-Through
No
Yes
Pass-Through Disk Attribute
SCSI ID : 0
SCSI LUN : 0
Write Protect : Disabled
Cache Mode : Write Back
Tag Queuing : Enabled
SCSI Channel : 0
3.7.4.2 Create Pass-Through Disk
A pass-through disk is not controlled by the SAS RAID controller
firmware and thus cannot be a part of a volume set. The disk is
available directly to the operating system as an individual disk.
It is typically used on a system where the operating system is
on a disk not controlled by the SAS RAID controller firmware.
The SCSI Channel/SCSI ID/SCSI LUN, Write Protect, Cache
Mode, and Tag Queuing must be specified to create a
pass-through disk.
