3 hot plugged disk for rebuilding, Bios configuration – Areca 24/4 Internal/External Port Pcie 3.0 12 Gb/s SAS/SATA Raid Controller 2Gb Cache User Manual
Page 96
BIOS CONFIGURATION
96
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
More System Functions
More System Functions
Smart Option For HDD
Smart Polling Interval
Hot Plugged Disk For Rebuilding
Hot Plugged Disk For Rebuilding
Hot Plugged Disk For Rebuilding
Blank Disk Only
Always
Disabled
Blank Disk Only
3.7.6.3 Hot Plugged Disk For Rebuilding
It defines if the RAID array volume should start rebuilding or
not when detects a disk is inserted/re-inserted during online.
The options are: “Blank Disk Only”, “Always”, and “Disable”. The
default is “Blank Disk Only”.
“Blank Disk Only”-it will trigger the rebuilding if and only if the
inserted disk has not been in the RAID array before, which has
no RAID signature on it. So when a previously removed disk is
self re-inserted, it won’t trigger the degraded RAID array to re-
build, and so that the administrator has a chance to identify this
mis-behaving disk and replaces it.
“Always” – it is what it was before. Whenever a disk is inserted/
re-inserted whether new or previously existed, it always trigger
a rebuilding for the Degraded RAID set/Volume.
“Disable” – it will not trigger rebuilding regardless what sort of
disk plugging in.When “Disable” and/or “Blank Disk Only” is se-
lected, the re-inserted/previously removed disk will be identified
as a disk in a separate RAID set with duplicated RAIDset#
and with all the rest of RAID members missing.
