ARCHTTP PROXY SERVER INSTALLATION
5.6 ArcHTTP Configuration
The ArcHTTP proxy server will automatically assign one additional
port for setup its configuration. If you want to change the “archttp
-
srv.conf” setting up of ArcHTTP proxy server configuration, for
example: General Configuration, Mail Configuration, and SNMP
Configuration, please start Web Browser http:\\localhost: Cfg As
-
sistant. Such as http:\\localhost: 81. The port number for the first
controller McRAID storage manager is ArcHTTP proxy server con
-
figuration port number plus 1.
•
General Configuration:
Binding IP: Restrict ArcHTTP proxy server to bind only single
interface (If more than one physical network in the server).
HTTP Port#: Value 1~65535
Display HTTP Connection Information To Console: Select “Yes" to
show Http send bytes and receive bytes information in the
console.
Scanning PCI Device: Select “Yes” for ARC-1883 series controller
Scanning RS-232 Device: No
Scanning Inband Device: No
• Mail (alert by Mail) Configuration:
Many users require that email notifications be sent to the
appropriate administrators when an alert is detected. To set up
your mail servers, click on the “Mail Configuration” link. The
“SMTP Server Configurations” allows you to define settings for
your mail server. This setup screen is shown as below:
