WEB BROWSER-BASED CONFIGURATION
172
6.7.6 Erase Failed Disk
To erase the failed encryption-capable physical disk, move the
cursor bar to the main menu and click on the “Erase Failed Disk ”
link. The “Select The Device To Erase” screen will show all failed
encryption-capable physical disks. Tick on the failed disk that you
want to erase and then click on the “Submit” button. In case con-
troller successfully performs an Instant Secure Erase, it will erase
all data on the encryption-capable physical disk disks and reset
the security attributes. The data on the encryption-capable physi-
cal disk is lost.
6.7.7 RevertSP
SED models will support the RevertSP feature which erases all
data in all bands on the device and returns the contents of all SPs
(Security Providers) on the device to their original factory state.
In order to execute the RevertSP method the unique PSID (Physi
-
cal Secure ID) printed on the drive label must be provided. PSID
is not electronically accessible and can only be manually read
from the drive label.
