BIOS CONFIGURATION
73
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Volume Set Function
Volume Set Functions
Creat Volume Set
Create Raid30/50/60
Delete Volume Set
Modify Volume Set
Check Volume Set
Stop Volume Check
Display Volume Info.
Create Volume Set
Create Volume From Raid Set
Raid Set # 00
Volume Creation
Volume Name : ARC-1883-VOL#000
Raid Level : 6
Capacity : 5039.9GB
Stripe Size : 64K
SCSI Channel : 0
SCSI ID : 0
SCSI LUN : 1
Cache Mode : Write Back
Write Protect : Disabled
Tag Queuing : Enabled
Cache Mode : : Write Back
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Volume Set Function
Volume Set Functions
Creat Volume Set
Create Raid30/50/60
Delete Volume Set
Modify Volume Set
Check Volume Set
Stop Volume Check
Display Volume Info.
Create Volume Set
Create Volume From Raid Set
Raid Set # 00
Volume Creation
Volume Name : ARC-1883-VOL#000
Raid Level : 6
Capacity : 5039.9GB
Stripe Size : 64K
SCSI Channel : 0
SCSI ID : 0
SCSI LUN : 1
Cache Mode : Write Back
Write Protect : Disabled
Tag Queuing : Enabled
Write Protect : Disabled
• Cache Mode
User can set the cache mode to either “Write Through” or
“Write Back”.
• Write Protect
When “Write Protect” is enabled on the “Create
Volume Set”,
host commands fail if they are issued to a volume in that
RAID controller and attempt to modify a volume’s data or at
-
tributes. “Write Protection” is used primarily for
customer-
initiated disaster recovery testing.
