BIOS CONFIGURATION
94
Multiples Of 1G:
If you have 123 GB drives from different
vendors; chances are that the capacity varies slightly. For ex
-
ample, one drive might be 123.5 GB, and the other 123.4 GB.
“Multiples Of 1G” truncates the fractional part. This makes the
same capacity for both of these drives so that one could replace
the other.
Disabled:
It does not truncate the capacity.
3.7.6 More System Functions
To set the “More System Functions”, move the cursor bar to the
main menu and select the “More System Functions” item and then
press Enter key. The “More System Functions” menu will show
multiple items. Move the cursor bar to an item, then press
Enter
key to select the desired function.
3.7.6.1 Smart Option For HDD
This option is used to increases the reliability of SSDs/HDDs by
automatically copying data from a drive with potential to fail to
a designated hot spare or newly inserted drive. The options are:
“Failed The Drive”, “Failed The Drive If Hot Spare Exist”, and
“Alert Only”. The default is “Alert Only”.
“Failed The Drive”- controllers kill off the SMART fail drive imme-
diately.
“Failed The Drive If Hot Spare Exist” – controllers kill off the
SMART fail disk if hot spare dive is existed.
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
More System Functions
