APPENDIX
212
2. FBM with Battery
B-4 Status of FBM
The following table provides the LED status of the FBM.
Figure B-2, ARC-1883-CAP
(upper view)
Figure B-1, ARC-1883-CAP
(top view)
Figure B-4, ARC-1883-BAT
(upper view)
Figure B-3, ARC-1883-BAT
(top view)
1. FBM with SuperCap
D2 (Blue)
Status
On
Power On
Off
Power Off
D14 (Blue)
Status
Charge
Slow Flash 1Hz
Charge-Done
On
Discharge
Quick Flash 10Hz
