BIOS CONFIGURATION
71
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Volume Set Function
Volume Set Functions
Creat Volume Set
Create Raid30/50/60
Delete Volume Set
Modify Volume Set
Check Volume Set
Stop Volume Check
Display Volume Info.
Create Volume Set
Create Volume From Raid Set
Raid Set # 00
Volume Creation
Volume Name : ARC-1883-VOL#000
Raid Level : 6
Capacity : 5039.9GB
Stripe Size : 64K
SCSI Channel : 0
SCSI ID : 0
SCSI LUN : 1
Cache Mode : Write Back
Write Protect : Disabled
Tag Queuing : Enabled
Stripe Size : 64K
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Volume Set Function
Volume Set Functions
Creat Volume Set
Create Raid30/50/60
Delete Volume Set
Modify Volume Set
Check Volume Set
Stop Volume Check
Display Volume Info.
Create Volume Set
Create Volume From Raid Set
Raid Set # 00
Volume Creation
Volume Name : ARC-1883-VOL#000
Raid Level : 6
Capacity : 5039.9GB
Stripe Size : 64K
SCSI Channel : 0
SCSI ID : 0
SCSI LUN : 1
Cache Mode : Write Back
Write Protect : Disabled
Tag Queuing : Enabled
SCSI Channel : 0
Warning:
Roaming the stripe size 256K/512K/1024K Raid Set to
firmware version older than 1.52 will cause data corrup
-
tion.
• Stripe Size
This parameter sets the size of segment written to each disk
in a RAID 0, 1, 1E, 10, 5, 6, 50 or 60 logical drive. You can
set the stripe size to 4 KB, 8 KB, 16 KB, 32 KB, 64 KB, 128
KB, 256KB, 512KB, or 1024KB.
The SAS RAID controller function simulates a external SCSI
RAID controller. The host bus represents the SCSI channel.
Choose the “SCSI Channel”. A “Select SCSI Channel” dialog
box appears; select the channel number and press the Enter
key to confirm it.
