INTRODUCTION
17
12Gb/s SAS RAID Controllers
Model Name
ARC-1883ix-12
ARC-1883ix-16
ARC-1883ix-24
I/O Processor
Dual Core
RAID-on-Chip 1.2GHz
Form Factor
(H x L)
Full Height: 98.4 x 254 mm
Host Bus Type
PCIe 3.0 x 8 Lanes
Driver Connector
3xSFF-8643
1xSFF-8644
4xSFF-8643
1xSFF-8644
6xSFF-8643
1xSFF-8644
Drive Support
Up to 256 12Gb/s SAS or 6Gb/s and 3Gb/s SAS/SATA HDDs
FBM/BBM Support
ARC-1883-CAP (support cache 2GB)/
ARC-1883-BAT (support cache 2GB, 4GB or 8GB)/
ARC-6120BA-T121-12G
RAID Level
0, 1, 1E, 3, 5, 6, 10, 30, 50, 60, Single Disk, JBOD
On-Board Cache
One 240-pin DIMM socket for 2GB(default) DDR3-1866, 1RX8,
ECC module
- up to 4GB or 8GB DDR3-1866, 1RX8, Unbuffered/Registered
ECC module or
- up to 4GB or 8GB DDR3-1600, 2RX8, Unbuffered/Registered
ECC module
Management Port
In-Band: PCIe
Out-of-Band: BIOS, LCD, LAN Port
Enclosure Ready
Individual Activity/Faulty Header, SGPIO, SMP, SES-2
