BIOS CONFIGURATION
57
Press Yes key in the “Create Vol/Raid Set” dialog box, the RAID
set and volume set will start to initialize it.
Select “Foreground (Faster Completion)” or “Background (Instant
Available)” for initialization and “No Init (To Rescue Volume)” for
recovering the missing RAID set configuration.
3.7.2 Raid Set Function
Manual configuration gives complete control of the RAID set set -
ting, but it will take longer to configure than “Quick Volume/Raid
Setup” configuration. Select “Raid Set Function” to manually con -
figure the RAID set for the first time or delete existing RAID sets
and reconfigure the RAID set.
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
Hdd Power Management
Ethernet Configuration
View System Events
Clear Event Buffer
Hardware Monitor
System information
Quick Volume/Raid Setup
Total 5 Drives
Raid 0
Raid 1 + 0
Raid 1 + 0 + Spare
Raid 3
Raid 5
Raid 3 + Spare
Raid 5 + Spare
Raid 6
Raid 6 +Spare
Raid 6
Available Capacity : 2400.0GB
Selected Capacity: 2400.0GB
Select Strip Size
4K
8K
16K
32K
128K
64K
Initialization Mode
Background (Instant Available)
No Init (To Rescue Volume)
Foreground (Faster Completeion)
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Raid Set Function
