3.7.3.4 Modify Volume Set
Use this option to modify volume set configuration. To modify
volume set values from RAID set system function, move the
cursor bar to the “Modify Volume Set” item, then press the
Enter
key. The “Volume Set Functions” menu will show all RAID
set items. Move the cursor bar to a RAID set number item, then
press the
Enter
key to show all volume set items. Select the
volume set from the list to be changed, press the
Enter
key to
modify it.
As shown, volume information can be modified at this screen.
Choose this option to display the properties of the selected
volume set. But user can only modify the last volume set
capacity.
3.7.3.4.1 Volume Growth
Use “Expand Raid Set” function to add disk to a RAID set. The
additional capacity can be used to enlarge the last volume set
size or to create another volume set. The “Modify Volume Set”
function can support the “Volume Modification” function. To
expand the last volume set capacity, move the cursor bar to
the “Capacity” item and entry the capacity size. When finished
the above action, press the
ESC
key and select the
Yes
option
to complete the action. The last volume set starts to expand its
capacity.
