Page 95
BIOS CONFIGURATION
95
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
More System Functions
More System Functions
Smart Option For HDD
Smart Polling Interval
Hot Plugged Disk For Rebuilding
Smart Option For HDD
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
More System Functions
More System Functions
Smart Option For HDD
Smart Polling Interval
Hot Plugged Disk For Rebuilding
Smart Polling Interval
Smart Polling Interval
On Demand
30 Seconds
1 Minute
5 Minutes
10 Minutes
20 Minutes
30 Minutes
1 Hour
2 Hours
3 Hours
6 Hours
12 Hours
On Demand
“Alert Only” – it will trigger alert when there happens a SMART
fail drive.
3.7.6.2 Smart Polling Interval
Besides the scheduled volume check, user can define the Smart
Pulling Interval to pull the SMART status of each disk. The de-
fault is “on demand”.
User can schedule every certain period of time interval to pull
the SMART status of each disk. When SMART pulling is executed,
disk activity will be temporally halted until the SMART parameter
reading is finished. That is why you don’t want to set the Inter
-
val too frequent. What to use is up to the users to decide based
on their applications and experiment results.
