WEB BROWSER-BASED CONFIGURATION
206
6.10.4 Hardware Monitor
The hardware monitor information of the enclosure attached in
this controller is also shown on this screen.
6.10.3 System Information
To view the SAS RAID controller’s system information, move the
mouse cursor to the main menu and click on the “System Infor-
mation” link. The SAS RAID controller “RAID Subsystem Infor-
mation” screen appears. Use this feature to view the SAS RAID
controller’s system information. The controller name, controller
firmware version, Boot ROM version, SAS firmware version, serial
number, main processor, CPU instruction/data cache size, system
memory size/speed and current IP address appear in this screen.
