BIOS CONFIGURATION
70
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Quick Volume/Raid Setup
Total 5 Drives
Raid 0
Raid 1 + 0
Raid 1 + 0 + Spare
Raid 3
Raid 5
Raid 3 + Spare
Raid 5 + Spare
Raid 6
Raid 6 + Spare
Raid 0
Greater Two TB Volume Support
No
Use 64bit LBA
Use 4K Block
No
If volume capacity will exceed 2TB, controller will show the
"Greater Two TB Volume Support" sub-menu.
• No
When this option is enabled, it keeps the volume size with
max. 2TB limitation.
For any hard disk drives working in the 4K native mode in
the Raid set, the volume set directly sets and exposes 4KB
sector size to the operating system.
• Use 64bit
LBA
This option use 16 bytes CDB instead of 10 bytes. The
maximum volume capacity up to 512TB. For any hard disk
drives working in the 4K native mode in the Raid set, the
volume set directly sets and exposes 4KB sector size to the
operating system. This option works on different OS which
supports 16 bytes CDB. Such as:
Windows 2003 with SP1 or later
Linux kernel 2.6.x or later
• Use 4K Block
This option uses 16 bytes CDB and changes the sector size
from default 512 bytes to 4k bytes. Windows XP only sup-
ports maximum volume capacity is up to 16TB.
