BIOS CONFIGURATION
44
The McBIOS RAID manager message remains on your screen for
about nine seconds, giving you time to start the configuration
menu by pressing
Tab
or
F6. If you do not wish to enter configu
-
ration menu, press
ESC to skip configuration immediately. When
activated, the McBIOS RAID manager window appears showing a
selection dialog box listing the RAID controllers that are installed
in the system. The legend at the bottom of the screen shows you
what keys are enabled for the windows.
2. M/B BIOS mode: UEFI and CSM (compatibility support module)
option = disabled
After firmware version 1.65 package, Areca RAID card ARC
-
1883FIRM.BIN code creates a virtual bootable disk (UEFI OS) for
the ARC-1883UEFI.BIN code to launch the McBIOS setup utility.
When user chooses to boot from the virtual disk in M/B setup, the
McBIOS setup utility is launched through boot into UEFI OS during
M/B boot. Follow below procedures to launch it.
a). Add RAID controllers “UEFI OS(Areca A....)” in the M/B boot
option: You must enter the setup of motherboard BIOS and add
UEFI OS to the boot option if your motherboard BIOS does not
automatically add it.
b). Restart your motherboard to boot from UEFI OS. The mother-
board vendors provide two methods for choosing a boot device:
Enter boot menu by using hotkey or enter boot menu through
BIOS configuration.
2.
M/B BIOS mode:
UEFI and CSM (compatibility support module)
option = disabled
Note:
UEFI OS is not loaded when setting the ‘Secure Boot’
option=enabled in M/B BIOS setup.
c). When booted, the McBIOS RAID setup window appears showing
the main menu of the RAID controllers that are installed in the
system. If there have more than two RAID adapters installed
in the system, it will show a selection for user to choose one to
configure the RAID adapter.
d). Follow the on-screen prompts to complete the configuration.
