Areca 24/4 Internal/External Port Pcie 3.0 12 Gb/s SAS/SATA Raid Controller 2Gb Cache User Manual
Page 141
141
ARCHTTP PROXY SERVER INSTALLATION
Mail Address: Enter the receiver's e-mail address. This is the
address you want the e-mail alerts sent to.
Ex: [email protected].
According to your requirement, set the corresponding event
level:
Disable Event Notification: No event notification will be sent.
Urgent Error Notification: Send only urgent events.
Serious Error Notification: Send urgent and serious events.
Warning Error Notification: Send urgent, serious and warning
events.
Information Notification: Send all events.
Notification For No Event: Notify user if no event occurs within
24 hours.
•
SNMP Traps Configuration:
This section discusses how to enable the SNMP traps on your
RAID storage, and how to control the sending of SNMP traps
from the ArcHTTP. To send the SNMP traps to client SNMP
manager such as Net-SNMP manager using the IP address
assigned to the operating system, you can simply use the SNMP
function on the ArcHTTP. The ArcHTTP only provides one direction
to send the trap to the SNMP manager without needing to install
the SNMP extension agent on the host. If SNMP manager
requests to query the SNMP information from RAID storage,
please refer the Appendix D "SNMP Operation & Installation".
To set up SNMP traps sending function, click on the “SNMP
Configuration” link. SNMP Traps Configurations are set up on this
page. This setup screen is shown as below:
The following article describes a best practice methodology for
setting this up in the “SNMP Traps Configurations”.
