APPENDIX
226
2. Mark the check box on the ‘SNMP Through PCI Inband” setting
and keep space (or zero) on all “SNMP Tarp IP Address” op-
tions.
3. Installing the SNMP extension agent on the server.
Please refer to next section of SNMP Extension Agent Instal-
lation for different operation system such as Windows, Linux
and FreeBSD.
D-3-4 SNMP Extension Agent Installation
The SNMP extension agent on the device is able to return mean
-
ingful, highly useful information to the SNMP manager. The Areca
RAID controllers have supported the extension agent for Win
-
dows, Linux and FreeBSD. This section is the detail procedures for
those extension agent installation.
D-3-4-1 Windows
You must have administrative level permission to install SAS
RAID controller extension agent software. This procedure as
-
sumes that the RAID hardware and Windows are both installed
and operational in your system. To enable the SNMP agent for
Windows, configure Windows for TCP/IP and SNMP services. The
Areca SNMP extension agent file is ARCSNMP.DLL.
Screen captures in this section are taken from a Windows XP
installation. If you are running another version of Windows, your
screens may look different, but the Areca SNMP extension agent
installation is essentially the same.
1. Insert the Areca RAID controller software CD in the CD-ROM
drive.
2. Double-click on the setup.exe file that resides at: <CD-
ROM>\packages\windows\SNMP on the CD. (If SNMP service
was not installed, please install SNMP service first.)
