BIOS CONFIGURATION
59
3.7.2.2 Delete Raid Set
To completely erase and reconfigure a RAID set, you must first
delete it and re-create the RAID set. To delete a RAID set, select
the RAID set number that you want to delete in the “Select Raid
Set To Delete” screen. Then “Delete Raid Set” dialog box will
appear, press the
Yes
to delete it. Warning, data on RAID set
will be lost if this option is used. But for deleting RAID set with
the Raid 30/50/60 volume,
firstly,
you need to delete the vol-
umes belonging those RAID sets.
Note:
To create RAID 30/50/60 volume, you need create multiple
RAID sets (up to 8 RAID sets) first with the same disk
numbers on each RAID set.
The max no. disk drives per
volume set:
32 for RAID 0/1/10/3/5/6 and 128 for RAID 30/50/60.
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Raid Set Function
Raid Set Function
Delete Raid Set
Expand Raid Set
Offline Raid Set
Activate Raid Set
Create Hot Spare
Delete Hot Spare
Rescue Raid Set
Raid Set Information
Create Raid Set
Select IDE Drives For Raid Set
[ ]E#1Solt#2 : 500.1GB : HDS725050KLA360
[ ]E#1Solt#3 : 500.1GB : ST3500630NS
[ ]E#1Solt#4 : 400.1GB : Hitachi HDT725040VLA360
[ ]E#1Solt#5 : 400.1GB : Hitachi HDT725040VLA360
[ ]E#1Solt#6 : 400.1GB : Hitachi HDT725040VLA360
[ ]E#1Solt#7 : 500.1GB : HDS725050KL360
[ ]E#1Solt#8 : 500.1GB : ST3500630NS
[*]E#1Solt#1 : 400.1GB : Hitachi HDT725040VLA360
Edit The Raid Set Name
aid Set # 000
R
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Raid Set Function
Raid Set Function
Delete Raid Set
Expand Raid Set
Offline Raid Set
Activate Raid Set
Create Hot Spare
Delete Hot Spare
Rescue Raid Set
Raid Set Information
Create Raid Set
Select Raid Set to Delete
Raid Set # 000 :3/3 Disk: Normal
Raid Set # 001 :9/9 Disk: Normal
Raid Set # 003 :8/8 Disk: Normal
Raid Set # 004 :3/3 Disk: Normal
Raid Set # 005 :3/3 Disk: Normal
Raid Set # 006 :3/3 Disk: Normal
Raid Set # 007 :3/3 Disk: Normal
Raid Set # 000 :3/3 Disk: Normal
Select Raid Set To Delete
Raid Set # 000
Are you Sure?
No
Yes
