Page 166
WEB BROWSER-BASED CONFIGURATION
166
Note:
Please make sure of the inconsistency source generated by
parity error or bad block before you click on the recovery
method. Otherwise, you will lose the recovery data.
6.6.7 Stop Volume Set Check
Use this option to stop the “Check Volume Set” function.
6.6.8 Download Volume Key File
Get the key file which was generated by CLI “vsf genkey” com
-
mand or API code for your ARC-1883 adapters. You can follow
below steps to download volume key file.
1. To download volume key file into the firmware, move the
mouse cursor to “Download Volume Key file” link and click on
it. The “Download Volume Encryption Key File” screen appears.
2. Click on “Browse”. Look in the location to which the key file was
generated. Select the file name and click “Open”.
3. Tick “Confirm The Operation” and press the “Submit” button.
4. After the key file download is completed, a bar indicator will
show “Key File Has Been Downloaded Successfully”.
