INTRODUCTION
16
• API library for customer to write manager utility
•
Single Admin Portal (ArcSAP) quick manager utility
Out-of-Band Manager
•
Firmware-embedded web browser-based McRAID storage man-
ager, SMTP manager, SNMP agent and Telnet function via
Ethernet port
•
API library for customer to write manager utility
•
Support push button and LCD display panel (optional)
Operating System
• Windows 10/8/Server 2012/7/2008/Vista/XP/2003
• Linux
•
FreeBSD
• VMware (Driver 6.x support CLI in-band management utility)
• Solaris 10/11 x86/x86_64
• Mac OS X 10.4.x or higher
(For latest supported OS listing visit
http://www.areca.com.tw
)
12Gb/s SAS RAID Controllers
Model Name
ARC-1883i
ARC-1883LP
ARC-1883x
I/O Processor
Dual Core
RAID-on-Chip 1.2GHz
Form Factor
(H x L)
Low Profile: 64.4 x 169.5 mm
Host Bus Type
PCIe 3.0 x 8 Lanes
Driver Connector
2xSFF-8643
1xSFF-8643
1xSFF-8644
2xSFF-8644
Drive Support
Up to 256 12Gb/s SAS or 6Gb/s and 3Gb/s SAS/SATA HDDs
FBM/BBM Support
ARC-1883-CAP / ARC-1883-BAT / ARC-6120BA-T121-12G
RAID Level
0, 1, 1E, 3, 5, 6, 10, 30, 50, 60, Single Disk, JBOD
On-Board Cache
2GB on-board DDR3-1866 SDRAM
Management Port
In-Band: PCIe
Out-of-Band: BIOS, LCD, LAN Port
Enclosure Ready
Individual Activity/Faulty Header, SGPIO, SMP, SES-2
