Page 145: Web browser-based configuration
145
WEB BROWSER-BASED CONFIGURATION
• Locally manage a system containing a supported RAID storage
that has Windows or Mac OS X, ArcHTTP and a supported
browser.
• Remote and managed systems must have a TCP/IP connection.
•
Start-up from Windows/Mac Local Administration
Once ArcHTTP and CLI have been installed, the ArcHTTP - back
ground task automatically starts each time when you start your
computer. There is one MARID icon showing on Mac “Desktop”
or one “
ArcHTTP Taskbar
”
icon showing on Windows
system tray. This icon is for you to start up the ArcHTTP (launch
the McRAID storage manager). When you click on the
ArcHTTP64 from MRAID or “
ArcHTTP Taskbar
” from system
tray, it shows all RAID controllers available on the host system
and create an individual RAID controller icon located on left
column of the “ArcHTTP Configurations” screen. This RAID con
-
troller icon is for user to launch the selected RAID controller
web browser McRAID storage manager.
The “Enter Network Password” dialog screen appears, type the
User Name and Password. The RAID controller default User
Name is “admin” and the Password is “0000”. After entering
the user name and password, press
Enter
key to access the
McRAID storage manager.
•
Start-up McRAID Storage Manager from Linux/
FreeBSD/Solaris Local Administration
To configure the internal SAS RAID controller. You need to
