BIOS CONFIGURATION
56
Stripe Size This parameter sets the size of the stripe written to
each disk in a RAID 0, 1, 1E, 10, 5, or 6 logical drive. You can
set the stripe size to 4 KB, 8 KB, 16 KB, 32 KB, 64 KB, 128 KB,
256KB, 512KB, or 1024KB.
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Quick Volume/Raid Setup
Total 5 Drives
Raid 0
Raid 1 + 0
Raid 1 + 0 + Spare
Raid 3
Raid 5
Raid 3 + Spare
Raid 5 + Spare
Raid 6
Raid 6 +Spare
Raid 6
Available Capacity : 2400.0GB
Selected Capacity: 2400.0GB
Select Strip Size
4K
8K
16K
32K
128K
256K
512K
1024K
64K
Warning:
Roaming the stripe size 256K/512K/1024K Raid Set to firm -
ware version older than 1.52 will cause data corruption.
A larger stripe size produces better-read performance, especially
if your computer does mostly sequential reads. However, if you
are sure that your computer performs random reads more often,
select a smaller stripe size.
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Quick Volume/Raid Setup
Total 5 Drives
Raid 0
Raid 1 + 0
Raid 1 + 0 + Spare
Raid 3
Raid 5
Raid 3 + Spare
Raid 5 + Spare
Raid 6
Raid 6 +Spare
Raid 6
Select Strip Size
4K
8K
16K
32K
128K
256K
512K
1024K
64K
Available Capacity : 2400.0GB
Selected Capacity: 2400.0GB
Create Vol/Raid Set
No
Yes
