BIOS CONFIGURATION
102
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Ethernet Configuration
Ethernet Configuration
DHCP Function : Enable
Local IP Address : 192.168.001.100
HTTP Port Number : 80
Telnet Port Number : 23
SMTP Port Number : 25
EtherNet Address : 00. 04. D9.7F .FF. FF
HTTP Port Number : 80
Edit The HTTP Port Number
0080 0
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Ethernet Configuration
Ethernet Configuration
DHCP Function : Enable
Local IP Address : 192.168.001.100
HTTP Port Number : 80
Telent Port Number : 23
SMTP Port Number : 25
EtherNet Address : 00. 04. D9.7F .FF. FF
Telnet Port Number : 23
Edit The Telent Port Number
0023 0
3.7.8.3 HTTP Port Number
To manually configure the “HTTP Port Number” of the controller,
move the cursor bar to “HTTP Port Number” item, then press the
Enter key to show the default address setting in the RAID con-
troller. Then You can reassign the default “HTTP Port Number” of
the controller.
3.7.8.4 Telnet Port Number
To manually configure the “Telnet Port Number” of the controller,
move the cursor bar to “Telnet Port Number” item, then press
the Enter key to show the default address setting in the RAID
controller. You can then reassign the default “Telnet Port Num-
ber” of the controller.
