BIOS CONFIGURATION
45
Areca Technology Corporation RAID Setup <V1.56, 2012/12/24>
ArrowKey Or AZ:Move Cursor, Enter: Select, **** Press F10 (Tab) to Reboot ****
Select An Adapter To Configure
( 001/ 0/0) I/O=28000000h, IRQ = 9
Use the
Up
and
Down
arrow keys to select the controller you want
to configure. While the desired controller is highlighted, press the
Enter
key to enter the main menu of the McBIOS RAID manager.
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Quick Volume/Raid Setup
Verify Password
Note:
The manufacture default password is set to
0000; this
password can be modified by selecting Change Password
in the
Raid System Function
section.
After using “F10” to exit, you can enter “ shell>exit” or need to
hard power cycle it.
e). Enter the setup of motherboard BIOS to disable or adjust UEFI
OS in the boot option priorities if it is the first priority of overall
boot order. Otherwise the system will always boot into UEFI OS
without using the hotkey.
McBIOS setup utility operates upon a single RAID controller at a
time. A selection dialog box listing the RAID controllers that are
installed in the system.
