WEB BROWSER-BASED CONFIGURATION
6.6.2 Create Raid30/50/60 (Volume Set
30/50/60)
To create 30/50/60 volume set from RAID set group, move
the cursor bar to the main menu and click on the “Create
Raid30/50/60” link. The “Select The Raid Set To Create Volume
On It” screen will show all RAID set number. Tick on the RAID set
numbers (same disk No per RAID set) that you want to create
and then click on the “Submit” button.
The new create volume set attribute allows user to select the Vol-
ume Name, Raid Level, Capacity, Greater Two TB Volume Support,
Initialization Mode, Strip Size, Cache Mode,
Write Protect, Full Vol-
ume Encryption, Tagged Command Queuing, and SCSI Channel/
SCSI ID/SCSI Lun. Please refer to above section for details de-
scription of each item.
Note:
RAID level 30 50 and 60 can support up to eight RAID
set
(four pairs), but it can not support expansion and migration.
