BIOS CONFIGURATION
69
• Raid Level
Set the “Raid Level” for the volume set. Highlight “Raid
Level” and press the
Enter
key. The available RAID levels for
the current volume set are displayed. Select a RAID level
and press the
Enter key to confirm.
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Volume Set Function
Volume Creation
Volume Name : ARC-1883-VOL # 000
Raid Level : 5
Capacity : 5039.9GB
Stripe Size : 64K
SCSI Channel : 0
SCSI ID : 0
SCSI LUN : 1
Cache Mode : Write Back
Write Protect : Disabled
Tag Queuing : Enabled
Raid Level : 6
Select Raid Level
0
0 + 1
3
6
5
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Volume Set Function
Volume Set Functions
Creat Volume Set
Create Raid30/50/60
Delete Volume Set
Modify Volume Set
Check Volume Set
Stop Volume Check
Display Volume Info.
Create Volume Set
Create Volume From Raid Set
Raid Set # 00
Volume Creation
Volume Name : ARC-1883-VOL# 000
Raid Level : 6
Capacity : 51GB
Stripe Size : 64K
SCSI Channel : 0
SCSI ID : 0
SCSI LUN : 0
Cache Mode : Write Back
Write Protect : Disabled
Tag Queuing : Enabled
Capacity : 5039.9GB
Available Capacity : 2400.0GB
Selected Capacity : 2400.0GB
• Capacity
The maximum available volume size is the default value for
the first setting. Enter the appropriate volume size to fit your
application. The capacity value can be increased or decreased
by the
UP
and
DOWN
arrow keys. The capacity of each vol
ume set must be less than or equal to the total capacity of
the RAID set on which it resides.
