BIOS CONFIGURATION
106
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
System Information
The System Information
Main Processor : 1200MHz PPC447
CPU ICache Size : 32KB
CPU DCache Size : 32KBs/Write Back
System Memory : 2GB/1866MHz/ECC
Firmware Version : V1.52 2014-01-31
BOOT ROM Version : V1.52 2014-01-01
PL Firmware Ver : 3.0.1.0
Serial Number : ARC-1883X0000000
Unit Serial # :
Controller Name : ARC-1883
Current IP Address : 192.168.0.103
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
More System Functions
Hdd Power Management
Ethernet Configuration
Alert By Mail Config
View System Events
Clear Event Buffer
Hardware Monitor
System information
Hardware Monitor
Controller H/W Monitor
CPU Temperature 58
Controller Temp. 43
CPU Fan 5625
12V 11.734
5V 4.999
3.3V 3.200
IO Voltage +1.8V 1.840
DDR3 +1.5V 1.536
CPU VCore +1.0V 1.040
Analog +1.0V 1.040
Battery Status Not Installed
3.7.13 System Information
Choose this option to display controller name,
firmware version,
BOOT ROM version, SAS firmware version, serial number,
main
processor, CPU instruction cache and data cache size, system
memory, and current IP address. To check the system informa-
tion, move the cursor bar to “System Information” item, then
press
Enter
key. All relevant controller information will be
displayed.
