APPENDIX
3.
SNMP Trap Notification Configurations
Please refer to
Appendix E
of Event Notification Configurations.
D-3-3 Using In-band PCI + SNMP Extension Agent Installa-
tion
By using the IP address assigned to the operating- RAID control-
ler using Areca SNMP extension agent through PCIe host bus
interface.
1. Set only “Community” field and select the “SNMP Port” option
on the firmware-embedded SNMP configuration function. There
is no function to set other fields on “SNMP System Configura-
tion”.
The SNMP community and SNMP port can setup by using
browser-based manager or CLI SNMP configuration. To launch
the above browser-based RAID controller SNMP function, click
on the “System Controls” link. The “System Controls” menu
will show available items. Select the “SNMP Configuration”
item. The following “SNMP System Configuration” screen is
launched by browser-based manager.
About community, Community name acts as a password
to screen accesses to the SNMP agent of a particular network
device. Type in the community names of the SNMP agent.
Before access is granted to a request station, this station must
incorporate a valid community name into its request;
otherwise, the SNMP agent will deny access to the system.
Most network devices use “public” as default of their
community names. This value is case-sensitive.
