Pearl Mini User Guide Set up the video output port using the Admin panel
By default, you can choose from the following output resolutions in 4:3 and 16:9 aspect ratios for your video
output ports, but you can also change settings to allow a variety of other resolutions through.
4:3 resolutions
1024Ч768 1280Ч960 1400Ч1050
16:9 resolutions
1280Ч720 1360Ч768 1920Ч1080
Set up the video output port using the Admin panel
You can send a channel or a video source to the video output port using the Admin panel. You can also adjust
the video output resolution, aspect ratio, and choose to include audio. The video output port frame rate is set
automatically to the channel's configured frame rate for that video source.
When outputting a channel that has audio or a video source with embedded audio, you can adjust the volume
and choose to include the audio meter. The audio meter is set to a fixed size of 15% of the width (or height if
displayed horizontally) of the display.
Important considerations
l Pearl-2 and Pearl Mini - If an SDI or HDMI video input source that is selected to display at the HDMI
output port also appears in a custom layout for a channel, then the channel's encoding settings are used
at the HDMI output. Changing the channel's frame rate will change the frame rate used at the output port
for that video input. If the video source appears in multiple layouts in different channels, the one with the
highest frame rate set in the encoding settings is used.
l Pearl-2 and Pearl Mini - Default auto channels have the related HDMI (or SDI) port selected by default.
As soon as you connect your video source to the port, it appears automatically in the auto channel's
custom layout. Changing the auto channel's frame rate or deleting the auto channel will change the frame
rate used at the output port for that video input. Deleting the auto channel forces the video output port to
use the original frame rate of the video input source.
To select the video you want to appear on the output port using the device screen or (for Pearl-2 and Pearl Mini)
Epiphan Live see
About video output ports .
Set up a channel or video source to display on the video output port using the Admin
panel
1. Login to the Admin panel as admin, see Connect to the Admin panel .
2. From the Output ports menu, click the output port ( HDMI for Pearl Mini). The video output port
configuration page opens.
123
