Pearl Mini User Guide Status and monitoring
Status and monitoring
Pearl Mini lets you monitor audio and check the status of your channels, live streams, and recordings.
Topics include:
l Monitoring audio
l Channel monitoring using the touch screen
l View system information using the touch screen
l View system information using the Admin panel
l View device information using the touch screen
l View network status
l View 802.1x network connection status
l View channel status and stream information
l View the video output port status
l View AFU and file transfer progress
l View scheduled CMS events and history
For a description of the front panel LEDs on Pearl Mini, see Front and back view of Pearl Mini .
Monitoring audio and VU sensitivity
You can connect headphones to the 3.5 mm audio jack on the front panel of Pearl Mini. To monitor audio for a
specific channel, just select the channel using the touch screen. The audio you hear depends on which layout is
currently live because different layouts can have different audio sources configured. To adjust the volume, tap
the headphones icon using the touch screen. See
Monitoring audio for details.
A VU meter on the touch screen shows the audio levels for the channel. The value is displayed in dBFS (decibels
relative to full scale). Colored bars represent the audio level.
